Geared Motor Technical Data
| Nominal voltage |
Reduction |
1/3.5 |
1/4.8 |
1/12 |
1/17 |
1/23 |
1/43 |
1/58 |
1/79 |
1/107 |
1/150 |
1/204 |
1/276 |
1/509 |
1/713 |
1/967 |
1/1313 |
1/1782 |
1/2418 |
| 24V |
| Torque(kg.cm) |
0.06 |
0.08 |
0.2 |
0.25 |
0.35 |
0.6 |
0.8 |
1 |
1.5 |
1.8 |
2.5 |
3.5 |
6 |
6 |
6 |
6 |
6 |
6 |
| Speed(rpm) |
2300 |
1700 |
670 |
490 |
360 |
190 |
140 |
100 |
75 |
55 |
40 |
28 |
16 |
12 |
9.3 |
7 |
5.3 |
4 |
Motor Specifications
| Model |
RF-180-1210 |
RF-180-2410 |
| Nominal voltage |
V |
12 |
24 |
| Noload Speed |
rpm |
10000 |
10000 |
| Noload Current |
A |
0.06 |
0.03 |
| Rated Speed |
rpm |
8200 |
8200 |
| Rated Current |
A |
0.29 |
0.15 |
| Rated Torque |
g.cm |
23 |
23 |
| Rated Output |
W |
1.9 |
1.9 |
| Stall Torque |
g.cm |
135 |
135 |
| Stall Current |
A |
1.4 |
0.7 |
Outline Drawing
